Feed & Flush Paint Feeding System is a trolley mounted system which contains two separate tanks one for Paint & another for Solvent easy to move anywhere in the Shop floor. The system is operated by a three way valve from where the operator can run Paint line or solvent line as & when required.
Feed & Flush system enhances your painting application performance as the system saves your paint & time. Due to separate solvent line availability, the operator can flush the system with solvent directly after the painting work done which is helpful in quick color change and saves Operator’s time a lot.
Bullows 9+9 Feed & Flush System contains one Paint tank of 9 ltr. capacity & another 9 ltr. tank for Solvent available in MS & SS with manual agitator and pneumatic agitator (optional).
|1||Paint tank capacity||9 Ltr|
|2||Solvent tank capacity||9 Ltr|
|3||Air hose size||5/16” I. D.|
|4||Paint hose size||1/4” I. D.|
|5||Safety valve release pressure||50 psi|
|6||Air inlet pressure||75 psi|
|7||Air hose connection||1/4” BSP (F) Swivel.|
|8||Paint hose connection||3/8” BSP (F) Swivel.|
